Detroit DD13, DD15, DD16 EPA07/10/GHG14 Engine Troubleshooting Manual

Covers: Detroit Diesel DD13, DD15, DD16 EPA 07/10/GHG14 Diesel Engines
Pages: 1,746
Format: PDF
File size: 44mb
Compatibility: Windows/Mac/Tablet/Smartphone

This 1,700+ page digital manual contains detailed troubleshooting and diagnostic instructions for Detroit Diesel DD13, DD15, DD16 engines with DDEC 6, DDEC 10 or DDEC 13 electronic controls (2007-2016). The troubleshooting manual is an essential guide for diesel mechanics diagnosing problems with the engine or DDEC electronic controls, with or without a code. Test procedures coupled with DDDL software usage instructions will help you pinpoint faults and get the vehicle back on the road.

A high-resolution, bookmarked, searchable and printable PDF will be delivered to you within minutes. The file can be permanently saved to your laptop, smartphone or tablet.

Topics:

• Electrical System
  • Detroit Diesel Electronic Control System
  • Motor Control Module
  • Common Powertrain Controller
  • Aftertreatment Control Module
  • Instrument Panel Lamps
• Engine Sensors
  • Sensor Overview
  • EPA07 Turbocharger Inlet Air Temperature Sensor
  • EPA07 Charge Air Cooler Outlet Air Temperature Sensor
  • Intake Manifold Air Temperature Sensor
  • Intake Pressure/Temperature Sensor
  • Crankshaft Position Sensor
  • Camshaft Position Sensor
  • Fuel Rail Pressure Sensor
  • Supply Fuel Temperature Sensor
  • Turbocharger Speed Sensor
  • Turbocharger Compressor Inlet Temperature Sensor
  • Water-in-Fuel Sensor
  • Delta P Sensor
  • Oil Pressure Sensor
  • Engine Coolant Level Sensor
  • Engine Oil Temperature Sensor
  • Description and Operation of the Oil Level/Temperature Sensor
  • Engine Coolant Inlet Temperature Sensor
  • Engine Coolant Outlet Temperature Sensor
  • Low Pressure Fuel Sensor
• Diagnostic Tests – Three-Filter Fuel System
• Diagnostic Tests – Two-Filter Fuel System
• Diagnostic Tests
  • Idle Speed Balance Test
  • DEF Quantity Test – EPA10
  • DEF Quantity Test – GHG14
  • EPA10 Perform Performance Check – Low Temperature ATD
  • GHG14 Perform Performance Check – Low Temperature ATD
  • Relative Cylinder Compression Test
  • Mechanical Cylinder Compression Test
  • Selective Catalyst Reduction Air Pressure System Check
  • Crankcase Pressure Test
  • Power Verification With Chassis Dynamometer
  • Minimum Acceptable Wheel Horse Power
  • Perform Output Component Test
  • Cylinder Leak Down Test
• Contaminated Fluids
• Symptom Diagnostics – Regeneration
• Symptom Diagnostics – Hard Start/No Start – Three-Filter Fuel System
• Symptom Diagnostics – Hard Start/No Start – Two-Filter Fuel System
• Excessive Oil Consumption
• Engine Coolant Temperature
• Excessive Exhaust Smoke
• Rough Running or Stalling
• Low Wheel Horsepower
• Excessive Noise
• Poor Engine Brake Performance
• Engine Manufacturer Diagnostics
• Virtual Technician
• SPN Code Troubleshooting
• System Diagrams
